Milesight Capacitive Level Sensor EM300-CL
Note: Power supply- ER18505 Li-SOCL2 battery: 4000 mAh or 8000 mAh
Battery Life: 5 years for 4000 mAh and 10 years for 8000 mAh (10 min interval)
The EM300-CL is a non-contact liquid level sensor based on LoRaWAN® technology, utilizing capacitive sensing principles. It is primarily used to monitor hand wash levels in restrooms, sending out alarms when the hand wash is insufficient. An alarm is triggered when the hand wash level approaches the electrode detection sheet, signaling a need for replenishment. It seamlessly integrates with containers of various shapes and sizes to ensure timely refills, promoting efficient smart hygiene and cleaning management systems.
With LoRaWAN technology supporting low power consumption, the built-in high-capacity battery lasts for several years without needing replacement. Additionally, the EM300-CL is compatible with both Milesight gateways and the Milesight IoT Cloud, enabling remote monitoring and smart data management, which aids in water conservation.
Features:
- High sensitivity real-time liquid level status monitoring with high stability and timely alarms
- Strong anti-interference ability and high accuracy based on an electrode pad with 2 electrode plates
- Non-contact liquid level detection for hygiene purposes
- Minimalist and lightweight electrode pad design for convenient installation
- IP67 waterproof performance for high applicability
- Built-in 4000mAh replaceable battery lasting up to 10 years without replacement
- Equipped with NFC for easy configuration
- Ultra-wide-distance transmission up to a line of sight of 10km
- Compliant with standard LoRaWAN gateways and network servers
- Quick and easy management with the Milesight IoT Cloud
