Regular price $ 210.00 $ 0.00

SKU: 123002983

EM500-LGT is designed for measuring light in harsh environments and transmitting data using LoRaWAN® technology. With this low power consumption technology, EM500-LGT can work up to 10 years with 19000 mAh battery. Combining with Milesight LoRaWAN gateway and Milesight IoT Cloud solution, users can manage all sensor data remotely and visually.

EM500-LGT is widely used for outdoor applications like smart agriculture, urban lighting, etc.

Features

  • Wide measuring range and high precision
  • Ultra-wide-distance transmission up to line of sight of 10km
  • IP67 waterproof enclosure for harsh environment applications
  • Built-in 19000 mAh replaceable battery and work for 10 years without replacement
  • Equipped with NFC for easy configuration
  • Compliant with standard LoRaWAN gateways and network servers
  • Quick and easy management with Milesight IoT Cloud solution

Applications

  • Smart buildings
  • Urban lighting
  • Greenhouse control
  • Smart agriculture
  • Weather Monitoring

Specifications

Wireless Transmission

Technology

LoRaWAN

Frequency

CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923

Tx Power

16dBm(868)/20dBm(915)/19dBm(470)

Sensitivity

-137dBm @300bps

Mode

OTAA/ABP Class A

Measurement

Range

0 - 100000 lux

Accuracy

±3%

Resolution

1 lux

Operation

Power On & Off

NFC, Power Button (Internal)

Configuration

Mobile APP(via NFC) or PC software(via USB Type-C)

Physical Characteristics

Cable Length

3 m

Power Supply

19000 mAh Li-SOCL2 battery (ER34615)

Battery Life*

10 years (10 min interval)

Operating Temperature

-30°C to +60°C

Relative Humidity

0% to 100% (non-condensing)

Ingress Protection

IP67(Transceiver)/IP65(Light Sensor)



Dimension

Transceiver: 105.4 × 71 × 69.5 mm (4.1 × 2.8 × 2.7 in)

Light Sensor: 64 × 58 × 34 mm (2.5 × 2.3 × 1.3 in)

Installation

Pole, wall or DIN Rail Mounting

Approvals

Regulatory

CE, FCC, RoHS
