Milesight PoE Injector

The Milesight PoE Injector adds 56V power to a Gigabit Ethernet link, so one cable carries both data and power to a camera or other PoE device. It suits sites where the switch has no PoE ports or where a single device needs power.

Key Features

• 30W output at 56V DC (0.535A)
• Gigabit Ethernet data pass-through
• AC input: 100-240V, 50/60Hz (90-264V range), C6 inlet
• Output on RJ45: pins 4,5 +56V, pins 7,8 return
• Over-voltage, over-current, and short-circuit protection; recovers on its own once a short is removed
• Efficiency: 87% minimum (DOE Level VI); no-load draw 0.1W or less
• Operating temperature: 0 to 40°C; humidity 10-90% non-condensing
• MTBF: 50,000 hours minimum at 25°C
• Dimensions: 118 x 43.7 x 31.4 mm
• Certifications: UL/cUL, CE, CB, RCM, FCC Class B; RoHS, WEEE, and REACH compliant

Technical Documents

• Engineering Specification Document
