Milesight UG65 Semi-industrial LoRaWAN Gateway
Milesight UG65 Semi-industrial LoRaWAN Gateway
SKU:123002005
Out of stock — Available on backorder
Couldn't load pickup availability
The Milesight UG65 is a robust, semi-industrial 8-channel LoRaWAN® gateway designed for reliable indoor and light outdoor deployments. Powered by the Semtech SX1302 LoRa® chip and a high-performance quad-core processor, the UG65 supports connectivity for over 2,000 end nodes, making it ideal for smart buildings, offices, campuses, and other IoT applications.
With a line-of-sight range of up to 15 km and urban coverage of approximately 2 km, the UG65 delivers strong, long-range performance in a compact, IP65-rated enclosure. It supports multiple backhaul options—Ethernet, Wi-Fi, and cellular (4G/3G)—and integrates seamlessly with leading LoRaWAN network servers.
Key Features
- High-Performance Architecture: Quad-core industrial-grade CPU with large memory for reliable, high-throughput operation.
- Advanced LoRa Capabilities: Equipped with the SX1302 chip for efficient handling of high traffic with low power consumption. Supports 8 full/half-duplex channels.
- Flexible Deployment Options: Supports desktop, wall, and pole mounting. IP65-rated enclosure allows for installation in semi-outdoor environments such as under eaves.
- Multi-Backhaul Connectivity: Redundant backhaul options via Ethernet, Wi-Fi, and optional cellular (4G/3G) ensure continuous connectivity.
- Flexible Network Server Options: Use the built-in LoRaWAN network server for quick deployment, or connect to any mainstream network server such as The Things Stack, ChirpStack, Actility, or Everynet.
- Secure Communications: Supports multiple VPN protocols including IPsec, OpenVPN, L2TP, PPTP, and DMVPN for secure data transmission.
- Developer-Friendly: Includes an embedded Python SDK and Node-RED for rapid prototyping and custom application development.
- Noise Analysis Tools: Built-in spectrum analysis tools help visualize noise levels for optimal gateway placement.
- API Integration: Supports MQTT, HTTP, and HTTPS APIs for easy integration with third-party platforms.
Technical Resources
Optional Accessories
- GA01-External LoRa Antenna - Enhance signal strength and coverage.
LoRa is a registered trademark of Semtech Corporation. LoRaWAN is a trademark of the LoRa Alliance. All other trademarks are the property of their respective owners.
