MCCI® Model 4841 Indoor Air Quality Sensor
Note: due to a fire at a semiconductor fab in Japan, the LoRaWAN module used in many MCCI IoT products is very hard to obtain. Please contact MCCI via email at email@example.com for current information on price and delivery of these products.
Remotely sense key air quality metrics PM1.0, PM2.5, PM10, dust concentration, total volatile organic compounds, temperature, and humidity. Transmit data using LoRaWAN® technology networks like The Things Network, Helium. machineQ, Senet, etc. Sigfox support also available. Small, attractive package 2 1/2" by 1 5/8" by 1 5/16". USB powered, with backup power for one to two weeks of unpowered data collection.
Case is white resin plastic.
USB charger and cable are included.
- Plantower PMS7003 particulate matter/dust concentrations
- TVOC: Sensirion SGPC3
- Temperature/RH: Sensirion SHT35.
Standard firmware transmits every 6 minutes. Open-source firmware; sources on GitHub at MCCI-Catena-PMS7003.
The US-915 variant targets the LoRaWAN US915 region. The EU868 variant targets the LoRaWAN EU868 region. Contact us for other regions or custom variants.
Please note: although the EU868 ships with a USB charger supporting 108 to 220 VAC input, the plug on the adapter is a fixed NEMA-style plug. Customer must provide suitable plug adapters.
